LC UPC to LC UPC OM4 50/125um Multi-mode Duplex 2.0mm Fiber Patch Cord

Product Description

The 50/125um OM4 multimode bend-insensitive tight-buffered fiber patch cord has lower attenuation when bent or twisted compared to traditional optical fiber cables. This makes the installation and maintenance of the fiber patch cord more efficient. We provide a full set of OEM Services, Such as fiber connector, length, color, fiber grade, package, etc…



Features

Conform to IEC, EIA-TIA, and Telcordia Performance

All Assemblies are machine polished providing highest quality

Available in custom length

RoHS compliant, Materials conflict compliant



Applications

Data Centers

Metro Network

Fiber Test Equipment

Wide Area Networks(WANs)

Telecommunications Network



Specification

Connector LC to LC Jacket OD 2.0mm
Fiber Mode 50/125um OM4 Jacket Color Aqua/Violet/Pink
Polish UPC to UPC Wavelength 850/1300nm
Fiber Type Duplex Jacket Material LSZH/PVC/OFNP
Insertion Loss ≤0.3dB Attenuation at 850nm 3.0dB/KM
Return Loss ≥30dB Attenuation at 1300nm 1.0dB/KM
Operating Temp. -40 ~ +75℃ Storage Temp. -45 ~ +85℃
Polarity A(Tx) to B(Rx) Minimum Bend Radius 30mm
