Product Description
24 Fiber MTP Fiber Optic Cables are designed to provide a more flexible multi-fiber cabling system based on MTP products. Unlike MTP Harness Cables, MTP Fiber Optic Cables are terminated with MTP connectors at both ends. MTP connectors at both ends, providing more options for existing 24-core cabling systems.
40/100G MTP Fiber Optic Cables eliminate wasted fibre in current 40G transmissions and upcoming 100G transmissions. Using an MTP fiber optic cable is more cost effective and has lower losses than than purchasing and installing a converter box separately.
ZHIDA also offers a full range of OEM services such as fiber connector, length, colour, fibre grade, specification, material, packaging, etc.
Features
1xMTP to 2x MTP Connectors
4Fibers, 8Fibers, 12Fibers, or 24Fibers version on request;
UPC or APC Polish available
Any other connector type at another side upon request
Fan-out on request
100% factory test(Insertion loss & return loss)
Applications
Telecommunication Networks
Data Center Infrastructure
Data Center Infrastructure
Precise installation networks
Wide Area Networks
Specifications
| Connector | 1xMTP to 2xMTP | Jacket Diameter | 3.0mm |
| Fiber Mode | 9/125um OS2 | Wavelength | 1310/1550nm |
| Polish Type | APC to APC | Jacket Material | LSZH/PVC/OFNP |
| Insertion Loss | ≤0.35dB | Return Loss | ≥60dB |
| Operating Temp. | -10~70℃ | Storage Temp. | -40~85℃ |
